400W 600W 700W Standard Model GA Series Outdoor rainproof LED driver power supply Specially designed for lighting projects and lightbox advertising signs
-
Design reliability ：Dual-Forward Converter ；Semi-cured glue, Fan cooling ；
-
Reliable Performance: Output power up to 400W with ≥89% efficiency and ±3% voltage regulation accuracy.
-
Output power: 400W, 600W, 700W; Output voltage: 12V, 24V.
-
Full Protection: Integrated overvoltage, overcurrent, and short circuit protection for safety and longevity.
-
Wide Operating Range: Operates smoothly in temperatures from -30°C to +50°C and in 5%~95% humidity (non-condensing).
-
Compact Design: Slim body (400W:205×110×45mm;600W/700W:213×117×51mm), easy to install in tight spaces. 30 units per carton.
-
Certified Quality: Complies with CE, RoHS, ISO9001, and CCC standards for global reliability.
Product Description
The 400GA 600GA 700GA series is a high-end engineering grade switching power supply,it is have constant voltage and constant current operating modes; it features a full metal housing and uses components from major brands, ensuring product stability and reliability. It is suitable for LED signage, lighting projects, lighting engineering, or security and surveillance systems. suitable for large outdoor landscape and building lighting projects.
Key Features:
-
Design reliability ：Dual-Forward Converter ；Semi-cured glue, Fan cooling ；
-
Reliable Performance: Output power up to 400W with ≥89% efficiency and ±3% voltage regulation accuracy.
-
Output power: 400W, 600W, 700W; Output voltage: 12V, 24V.
-
Full Protection: Integrated overvoltage, overcurrent, and short circuit protection for safety and longevity.
-
Wide Operating Range: Operates smoothly in temperatures from -30°C to +50°C and in 5%~95% humidity (non-condensing).
-
Compact Design: Slim body (400W:205×110×45mm;600W/700W:213×117×51mm), easy to install in tight spaces. 30 units per carton.
-
Certified Quality: Complies with CE, RoHS, ISO9001, and CCC standards for global reliability.
Applications:
- LED lightboxes and illuminated signage
- Billboard lighting systems
- Architectural façade lighting
- CCTV and security system power supply
- Trade show and exhibition lighting
| Product selection | ZY-400GA-12 | ZY-400GA-24 | ZY-600GA-12 | ZY-600GA-24 |
|---|---|---|---|---|
| Input voltage | 176～264VAC | |||
| Output voltage/current | 12V 33A | 24V 16.5A | 12V 50A | 24V 25A |
| Voltage regulation accuracy | ±5% | ±3% | ±5% | ±3% |
| Efficiency | ≥90% | ≥91% | ≥91% | ≥92.5% |
| Protection feature | Overcurrent protection、Overvoltage protectionshort 、Short circuit protection | |||
| Reference standards | GB4943/IEC62368、GB2324、EN55022、IEC61000、GB 17625、GB/T17626、GB/T14714 | |||
| Operating temperature/humidity | -40℃~50℃；5%~95%RH non-condensing | |||
| Altitude | 2000m（Above 3000m, the height rises by 100m，Environment temperature drops 0.6℃） | |||
| Three-proof requirements | Semi-poured glue | |||
| Heat dissipation method | Fan cooling | |||
| Product appearance dimensions | 201*118*50mm | 213*118*51mm | ||
| Product packaging weight | 670g | 810g | ||
| Quantity per box | 30PCS | 30 | ||
| outer box dimensions | 648*295*267mm | 675*310*270mm | ||
| weight per box | 20.8kg | 25.3kg | ||
FAQ
When can I get the quotation?
We usually quote within 8 hours after receiving your inquiry. If you are having a very urgent project that needs our quick response, please call us or tell us in your email so that we will regard your inquiry as a priority.
How can I get a sample for quality check?
After price confirmation, you can require samples to check our quality. If you need samples, we will charge the sample cost. But the sample cost can be refunded after order confirmation and the quantity exceeds our MOQ.
Why should you buy from us not from other suppliers?
- With more than 500 workers to ensure timely delivery.
- Our R&D team with more than 20 years' experience on lighting business.
- Platinum partner of OSRAM, Strategic partner of EUCHIPS.
- CB,CE,ROHS,COC,BIS,SAA,ETL certifications approved.
What services can we provide?
We offer the following services and terms:
- Delivery Terms: FOB, CFR, CIF, EXW, CIP, Express Delivery
- Accepted Payment Currencies: USD, EUR, HKD, GBP, CNY
- Accepted Payment Methods: T/T, L/C, Credit Card, PayPal, Western Union, Cash
- Languages Spoken: English, Chinese, Spanish, Japanese
Can you provide ODM/OEM service?
Yes,we have more than 20 years experience in lighting business and we are sure can provide ODM/OEM service for customers.
What's your delivery date?
Usually different items have different delivery date; normal products the delivery date for bulk production is around 20-30 days. For sample is 7-10days.
